KDF11-AA

This manual provides comprehensive technical information for the KDF11-AA 16-bit microprocessor. Key sections include:

• Specifications: Details on the KDF11-AA module (M8186), including architectural features, memory management, and electrical characteristics.
• Installation: Procedures for jumper configuration, backplane selection, and module installation.
• Console ODT: Operation of the on-board Console Octal Debugging Technique for system debugging.
• LSI-11 Bus: Detailed protocol for bus cycles, DMA, and interrupts.
• Functional Description: Deep dive into the data, control, and memory management (MMU) chips.
• Instruction Set: Complete list and format descriptions of the processor's over 400 instructions, including floating-point operations.
• Programming Techniques: Guidance on using position-independent code, stack operations, subroutines, and interrupts.

It also includes extensive appendices for programming references, bus timing, and integrated circuit specifications.
