Bootstrap/Terminator Module

This document is a comprehensive maintenance and operator's manual for the M9301 Bootstrap/Terminator module, designed for use in various PDP-11 computer systems. It covers the module's general description, hardware features, and electrical specifications. The manual provides detailed instructions for installation, including switch settings for memory addressing and power-up boot configurations. It also explains the use of the built-in console emulator, which allows users to perform operations like loading addresses, examining and depositing data, and initiating bootstrap routines from peripherals. Specific chapters are dedicated to the unique functions and diagnostics for different module variations, including the M9301-YA, YB, YC, YD, YE, YF, YH, and YJ models. It serves as a guide for system configuration, troubleshooting, and understanding diagnostics through register displays.
