VK100

This technical manual provides detailed information on the VK100 (GIGI) graphics terminal. It includes:

• Installation Procedures: Site considerations, hardware setup, and cabling configurations.
• Operating Information: Keyboard controls, setup parameters, and modes of operation.
• Programming Summary: Keyboard codes, character sets, and comprehensive details on ANSI and VT52 control functions, as well as ReGIS and BASIC command structures.
• Theory of Operation: Block-level descriptions of the terminal's components, including the CPU, vector generator, I/O ports, and power supply.
• Testing and Troubleshooting: Self-test procedures, error reporting, and field replacement instructions.
• Appendices: Detailed terminal specifications and calculation examples.
