RX01 Plenum and Fan Assembly

This document contains a field maintenance print set for the RX01 plenum and fan assembly. It includes:

• Plenum Interconnection Charts: Detailed diagrams and instructions for wiring the fan assembly, power supply (H771), and floppy disk drive power connections.
• Assembly Drawings: Technical illustrations of the plenum, fan, and mounting hardware.
• Parts Lists: Extensive lists of hardware kits, labels, and sub-assemblies for various RX01 and RX02 configurations.
• Assembly Notes: Specific instructions on the permanent attachment of wires to the fan and cable routing for series connections.
