Power Supply and Connections

This document contains a set of engineering drawings for the H771 power supply series, including the H771-A-1, H771-C-1, and H771-D-1 configurations. The documentation includes:

• Parts List and Drawing Index: A summary of mechanical and electrical drawings.
• Schematics: Detailed electrical wiring diagrams showing connections for power supply components, disk control boards, and spin motors.
• Board Assembly Layouts: Component side diagrams for the RX01 power board assembly, including component identification and placement notes.
• Assembly Specifications: Wiring tables and technical notes for specific component configurations and assembly requirements.
