KFTHA System I/O Module

This installation card guides users through the installation of the KFTHA I/O module (E2052) into AlphaServer 8200/8400 systems. It covers the following key procedures:

• Location Determination: Identifying the correct slot (highest-numbered available slot between 6 and 8).
• Module Removal: Safety precautions and steps to remove existing terminator modules.
• Module Insertion: Detailed instructions on aligning and inserting the new module into the card cage.
• Cable Connection: Guidelines for connecting I/O cables with proper torque specifications.
• System Verification: Procedures for confirming a successful installation using self-test LEDs and system console displays.
