4-Bit Arithmetic Logic Unit

This document provides the schematic diagram for the M159 4-bit Arithmetic Logic Unit (ALU). It details the pin connections for a DEC74181 integrated circuit, including input signals (A and B lines) and output signals (F lines), alongside power and grounding configurations. The document is provided by the Digital Equipment Corporation for test and maintenance purposes only.
