M770 EAE Control

This document provides an overview of the M770 module, which contains a 6-bit timing generator and EAE control logic. The M770 is designed for use within the PDP-15 central processor equipped with the EAE option. Key characteristics include:

• Inputs and Outputs: Standard TTL levels.
• Power: Maximum power dissipation of 5V at 500 mA.
