DECnet-11M-PLUS

Overview

DECnet-11M-PLUS Version 4.0 is a Phase IV network product designed for the RSX-11M-PLUS operating system. It allows systems to act as either routing or non-routing (end) nodes within a DECnet computer network, supporting communication through various hardware interfaces including Ethernet, serial lines, and X.25 circuits via RSX-11 P.S.I./M-PLUS.

Key Features

• Network Functionality: Provides task-to-task communication, network file operations, resource sharing, and remote command terminal support (via CTERM and LAT).
• Routing: Supports adaptive routing and Area Routing (up to 63 areas with 1023 nodes per area).
• Management: Includes the Network Control Program (NCP) for displaying statistics, controlling components, and logging network events.
• Utilities: Offers file transfer utilities (supporting both FCS and RMS files) and remote job submission.

Hardware/Software Requirements

• Prerequisite: RSX-11M-PLUS (Version 4.0 minimum).
• Memory: Minimum requirements range from 22KW (end node) to 36KW (routing node with P.S.I.).
• Configuration: Configuration depends on trade-offs between cost, performance, and specific application needs, with CPU and communication interface types directly affecting node performance and load.

Ordering

Licensing is required per CPU, with options for Full Function or End Node versions, along with various support and service packages.
