Control Handbook

This handbook serves as a primary technical resource for Digital Equipment Corporation's industrial solid-state control products, specifically the K Series logic modules. It provides extensive data on the K Series, including specifications, logic symbols, and detailed descriptions of gating, memory, timing, and interface modules. The document also covers the PDP-14 programmable controller, offering insights into its operation and programming. Additionally, it details hardware accessories for industrial control systems, such as mounting panels, power supplies, and wiring aids, and provides a section on A Series analog modules. The book is structured to assist engineers in specifying, designing, and manufacturing industrial control systems, with information on transitioning from relay logic to solid-state control, addressing noise immunity, and system construction.
