Logic Handbook

This document is the 1973-74 edition of the Digital Equipment Corporation (DEC) Logic Handbook. It provides a detailed catalog and guide to the M Series TTL integrated circuit modules, which range from basic logic gates to complex computer interfacing subsystems. The handbook is structured into several functional sections, including:

• M Series Logic and Control Modules: Details over 100 modules for general logic and instrumentation.
• M Series Modules for Computer Interfacing: Covers interfacing with PDP-11 (UNIBUS), PDP-8/e/m (OMNIBUS), and earlier PDP-8 family systems.
• Analog (A Series) Modules: Supports analog signal processing with multiplexers, amplifiers, and A/D and D/A converters.
• Accessory Modules (W Series): Includes wire-wrappable boards, collage boards, and blank modules.
• DECkits: Modular kits for interfacing PDP-11 systems.
• Power Supplies, Cables, and Hardware: Comprehensive listings for supporting power units, specialized cables, mounting panels, drawers, and cabinets.
• Data Entry Terminals: Information on the RT01 and RT02 terminals.

The handbook also serves as a reference for signal naming conventions, operating characteristics (voltage, noise margins, timing), and engineering services provided by DEC.
