AD11-K Analog to Digital Converter

The AD11-K is a 12-bit successive approximation analog-to-digital converter designed for PDP-11 systems. This manual covers the technical specifications, including its 16 single-ended or 8 differential input channels and 50 kHz throughput. It details user installation, including wiring for grounded or floating inputs, jumper configurations for voltage ranges, and switch settings for addressing. Finally, it explains the register programming, providing a code example for data acquisition.
